Description:
The ICLV-01 is a brass-bodied, two-way headed landing/hydrant valve designed for fire-fighting systems. It features a dual-outlet configuration that allows two simultaneous water streams from a single supply. The valve is constructed for manual operation, equipped with a cast-iron hand wheel, and is suited for outdoor hydrant installations.
Key listed details: model ICLV-01; body material brass; manual operation; working pressure up to 12 bar maximum; 4″ flange (Class 150) inlet with 190 mm PCD; outlet(s) are 2.5″ male instantaneous couplings conforming to BS-336.
Key Features:
-
Material: Brass Body: corrosion resistant and suitable for fire-hydrant applications.
-
Dual Outlet (Two-Way Headed): provides two discharge paths for increased flexibility in fire attack.
-
Working Pressure: 12 bar (Max): suitable for typical hydrant line pressures.
-
Inlet: 4″ Flange, Class 150, 190 mm PCD: accommodates large supply line connection.
-
Outlets: 2.5″ Male Instantaneous BS-336: supports standard fire-hose coupling interfaces.
-
Manual Hand Wheel (Cast Iron): practical for manual valve operation.
Finish: Red Body / Black Hand Wheel: standard fire equipment identification
Industrial Uses / Applications:
-
Hydrant systems at oil & gas refineries
-
Petrochemical & fuel depots where dual outlets are needed
-
Industrial fire-hydrant systems in large manufacturing plants
-
Marine & offshore firefighting fixed hydrant stations
-
Airport hydrant installations and high-capacity fire-water supply zones
